113RF-1-A-5/2D Reed Relay
SPST N.O., 5V Coil, 0.5 Amp, 10 Watts, 200 Volts, 230 V Standoff
$12.99 Excl. Vat, Tax and Duties
4-6 weeks for additional manufactured stock
Availability: 330 in stock
Discount per quantity
| Quantity | 1 - 24 | 25 - 99 | 100 - 249 | 250+ |
|---|---|---|---|---|
| Price | $12.99 | $11.69 | $11.04 | $10.39 |
Pickering Series 113RF
- Coaxial Reed Relays
- For up to 3 GHz
- Designed and manufactured by Pickering in the UK and Czech Republic (EU)
| Dimensions | 55663927 × 556629 mm |
|---|---|
| PEL Contact Configuration | 1 Form A – SPST N.O. |
| PEL Switching Current (Amps) | 0.5 |
| PEL Switching Power (Watts) | 10 |
| PEL Switching Voltage | 200 |
| PEL Standoff Voltage | 230 |
| PEL Coil Voltage | 5V |
| PEL Coil Resistance | 300 ? |
| PEL Diode | Yes |
| PEL Depth (mm) | 3.7 |
| PEL Width (mm) | 12.5 |
| PEL Height (mm) | 6.6 |
| PEL Series | Series 113RF |
| PEL Switch Type | Low Level |
