Older Pickering Reed Relay Styles

All Pickering Reed Relays feature the highest quality instrumentation grade reed switches making them suitable for the most demanding applications.

These ranges have been manufactured for many years. Most sold today are for service replacements - proving Pickering's long term commitment to our products and to our customers

Pickering Series 80, 85, 88 & 89

General Purpose Reed Relays
Dry and mercury wetted

• SoftCenter™ construction
• Encapsulated in a plastic package with internal mu-metal magnetic screen
• Wide range of switch configurations
• Many benefits compared to industry standard relays. Learn more here >.
• Dry and mercury wetted switches are available with the same pin configuration
• 5, 12 and 24 volt coils are standard, with or without internal diode

These ranges of reed relays are available with both dry and mercury wetted switches. They are available with 5, 12 and 24 volts coils, a particularly useful feature of the 5 volt dry devices is their ability to be driven directly from TTL, the coil requiring only 10mA of drive current.

All units have an internal magnetic screen and can be supplied with built-in diode if required.

Standard coil voltages are 5, 12 and 24 volts. All relays are fitted with internal magnetic screen to avoid stray magnetic interaction between adjacent relays.

Many special coil resistances are available, and relays can be designed to customers specific requirements

Download Data Sheet PDF More Info & 3D Models

Request Evaluation Samples Request a Quote

The below table will help you narrow down our offering to get you the correct reed relay for your application.

Once you narrow your selections down you can download a reed relay data sheet for more information or request a quote to find out prices and lead times.

If you experience any technical difficulties whilst loading this page, please clear your browser cache and reload. Still having trouble? Contact us here

Scroll right to view full data information

Showing 1 – 20 of 108 results Showing all 108 results Showing the single result No results found

Clear filters

Part Number	Contact Configuration	Switching Current (Amps)	Switching Power (Watts)	Switching Voltage (DC or AC peak)	Stand-off Voltage (DC or AC peak)	Coil Voltage	Coil Resistance (Ω)	Switch Type	Diode	Depth (mm)	Width (mm)	Height (mm)	View Datasheet	Stock	Price	Add to Bag
89-1-A-12/1	1 Form A - SPST N.O.	2 Amps	50	500	550	12V	750 Ω	Std Mercury Reed	No	9.9	29	9.4	View PDF	0 - MTO	$22.78	Add to RFQ list This product is already in quote list. Browse the list
89-2-A-5/1D	1 Form A - SPST N.O.	2 Amps	50	200	550	5V	1750 Ω	Std Mercury Reed	Yes	13.2	29	9.4	View PDF	1		Max: 1 Min: 1 Step: 1 Add
89-2-A-5/1	1 Form A - SPST N.O.	2 Amps	50	200	550	5V	1750 Ω	Std Mercury Reed	No	13.2	29	9.4	View PDF	0 - MTO		Add to RFQ list This product is already in quote list. Browse the list
89-1-A-5/1D	1 Form A - SPST N.O.	2 Amps	50	500	550	5V	140 Ω	Std Mercury Reed	Yes	9.9	29	9.4	View PDF	0 - MTO	$23.44	Add to RFQ list This product is already in quote list. Browse the list
89-1-A-5/1	1 Form A - SPST N.O.	2 Amps	50	500	550	5V	140 Ω	Std Mercury Reed	No	9.9	29	9.4	View PDF	7	$22.78	Max: 7 Min: 1 Step: 1 Add
89-2-A-24/1D	1 Form A - SPST N.O.	2 Amps	50	500	550	24V	430 Ω	Std Mercury Reed	Yes	13.2	29	9.4	View PDF	0 - MTO		Add to RFQ list This product is already in quote list. Browse the list
89-2-A-24/1	1 Form A - SPST N.O.	2 Amps	50	500	550	24V	430 Ω	Std Mercury Reed	No	13.2	29	9.4	View PDF	0 - MTO		Add to RFQ list This product is already in quote list. Browse the list
89-2-A-12/1	2 Form A - DPST N.O.	2 Amps	50	500	550	12V	430 Ω	Std Mercury Reed	No	13.2	29	9.4	View PDF	0 - MTO	$40.61	Add to RFQ list This product is already in quote list. Browse the list
89-1-B-5/1D	1 Form A - SPST N.O.	2 Amps	50	200	550	5V	2000 Ω	Std Mercury Reed	Yes	9.9	29	9.4	View PDF	0 - MTO		Add to RFQ list This product is already in quote list. Browse the list
89-1-A-24/1	1 Form A - SPST N.O.	2 Amps	50	200	550	24V	2000 Ω	Std Mercury Reed	No	9.9	29	9.4	View PDF	5	$22.78	Max: 5 Min: 1 Step: 1 Add
89-1-A-12/1D	1 Form A - SPST N.O.	2 Amps	50	500	550	12V	750 Ω	Std Mercury Reed	Yes	9.9	29	9.4	View PDF	2	$23.44	Max: 2 Min: 1 Step: 1 Add
88-1-A-24/1	1 Form A - SPST N.O.	2 Amps	50	500	550	24V	2000 Ω	Std Mercury Reed	No	9.9	29	9.4	View PDF	0 - MTO	$22.78	Add to RFQ list This product is already in quote list. Browse the list
88-1-B-5/1D	1 Form B - SPST N.C.	2 Amps	50	500	550	5V	90 Ω	Std Mercury Reed	Yes	13.2	29	9.4	View PDF	0 - MTO	$29.78	Add to RFQ list This product is already in quote list. Browse the list
88-1-A-12/1D	1 Form A - SPST N.O.	2 Amps	50	500	600	12V	750 Ω	Std Mercury Reed	Yes	9.9	29	9.4	View PDF	0 - MTO	$23.44	Add to RFQ list This product is already in quote list. Browse the list
88-1-B-5/1	1 Form B - SPST N.C.	2 Amps	50	500	550	5V	90 Ω	Std Mercury Reed	No	13.2	29	9.4	View PDF	0 - MTO	$29.02	Add to RFQ list This product is already in quote list. Browse the list
88-1-A-12/1	1 Form A - SPST N.O.	2 Amps	50	500	600	12V	750 Ω	Std Mercury Reed	No	9.9	29	9.4	View PDF	0 - MTO	$22.78	Add to RFQ list This product is already in quote list. Browse the list
88-2-A-12/1D	2 Form A - DPST N.O.	2 Amps	50	500	550	12V	430 Ω	Std Mercury Reed	Yes	13.2	29	9.4	View PDF	99	$41.29	Max: 99 Min: 1 Step: 1 Add
88-1-B-24/1D	1 Form B - SPST N.C.	2 Amps	50	500	550	24V	1750 Ω	Std Mercury Reed	Yes	13.2	29	9.4	View PDF	5	$29.78	Max: 5 Min: 1 Step: 1 Add
88-2-A-12/1	2 Form A - DPST N.O.	2 Amps	50	500	550	12V	430 Ω	Std Mercury Reed	No	13.2	29	9.4	View PDF	0 - MTO	$40.61	Add to RFQ list This product is already in quote list. Browse the list
88-1-B-24/1	1 Form B - SPST N.C.	2 Amps	50	500	550	24V	1750 Ω	Std Mercury Reed	No	13.2	29	9.4	View PDF	0 - MTO	$29.02	Add to RFQ list This product is already in quote list. Browse the list
