131-1-A-5/1 Reed Relay
$14.97 Excl. Vat, Tax and Duties
Additional stock lead time: 4-6 weeks* Lead time is approximate and may vary. Please contact us for a more specific estimated time from for your order.
No stock available - made to order. Please add to request for quote list
Discount per quantity
| Quantity | 1 - 24 | 25 - 99 | 100 - 249 | 250+ |
|---|---|---|---|---|
| Price | $14.97 | $13.47 | $12.72 | $11.98 |
Please note - Prices above excl. tax and duties
For availability, lead time and delivery options please request a quote. For larger quantities fill out this form
Request a Free Sample < Back to the Reed Relay SelectorPickering Series 131
- Smallest High Voltage SIL Reed Relays with Low-Level Switch
- Up to 10 W switching
- 1kV standoff
- 5 Volt coil
- Designed and manufactured by Pickering in the UK and Czech Republic (EU)
To learn more about this series click here
Many benefits compared to industry-standard relays. Learn more here
Custom options are available. Learn more here
| Dimensions | 55663927 × 556629 mm |
|---|---|
| PEL Switching Voltage | 1000 |
| PEL Standoff Voltage | 1500 |
| PEL Depth (mm) | 3.7 |
| PEL Height (mm) | 6.6 |
| PEL Diode | No |
| PEL Width (mm) | 12.5 |
| PEL Switch Type | 1.5KV Standoff |
| PEL Contact Configuration | 1 Form A – SPST N.O. |
| PEL Switching Power (Watts) | 10 |
| PEL Switching Current (Amps) | 0.7 |
| PEL Coil Resistance | 250 Ω |
| PEL Coil Voltage | 5V |
| Series | Series 131 |
| Contact Configuration | 1 Form A – SPST N.O. |
| Coil Resistance | 250 Ω |
| Coil Voltage | 5V |
| Switching Current (Amps) | 0.7 |
| Switching Power (Watts) | 10 |
| Switching Voltage | 1000 |
| Depth (mm) | 3.7 |
| Width (mm) | 12.5 |
| Height (mm) | 6.6 |
| Standoff Voltage | 1500 |
| Diode | No |
