86-2-A-12/1D

$14.11 Excl. Vat

SKU: 86-2-A-12/1D Category:

Description

Pickering Series 87

  • High Sensitivity Reed Relays
  • Dry and mercury wetted



Download Data Sheet PDF

Additional information

Relay Specs
PEL Contact Configuration

2 Form A – DPST N.O.

PEL Switching Current (Amps)

0.5

PEL Switching Power (Watts)

10

PEL Switching Voltage

200

PEL Standoff Voltage

240

PEL Coil Voltage

12V

PEL Coil Resistance

3000 Ω

PEL Switch Type

General Dry Reed

PEL Diode

Yes

PEL Depth (mm)

13.2

PEL Width (mm)

29

PEL Height (mm)

9.4

More
PEL Series

Series 86

Series

Series 86

Contact Configuration

2 Form A – DPST N.O.

Switching Power (Watts)

10

Coil Resistance

3000 Ω

Diode

Yes

Coil Voltage

12V

Switching Current (Amps)

0.5

Switching Voltage

200

Standoff Voltage

240

Depth (mm)

13.2

Width (mm)

29

Height (mm)

9.4
