Pickering Series 102
- Low Capacitance SIL Reed Relays
- Up to 10 W switching
- 240kV stand-off
- 5 Volt coil
- Designed and manufactured by Pickering in the UK and Czech Republic (EU)
To learn more about this series click here
$18.52 Excl. Vat, Tax and Duties
Contact us for additional stock lead time
No stock available - made to order. Please add to request for quote list
ComparePlease note - Prices above excl. tax and duties
For availability, lead time and delivery options please request a quote. For larger quantities fill out this form
Request a Free Sample < Back to the Reed Relay SelectorTo learn more about this series click here
Dimensions | 55663927 × 556629 mm |
---|---|
Series | Series 102 |
Contact Configuration | 1 Form B – SPST N.C. |
Switching Current (Amps) | 0.5 |
Switching Power (Watts) | 10 |
Switching Voltage | 200 |
Standoff Voltage | 240 |
Coil Voltage | 5V |
Coil Resistance | 1000 Ω |
Diode | No |
Depth (mm) | 4.8 |
Width (mm) | 19.1 |
Height (mm) | 10.2 |
PEL Series | Series 102 |
PEL Coil Voltage | 5V |
PEL Contact Configuration | 1 Form B – SPST N.C. |
PEL Coil Resistance | 1000 Ω |
PEL Switching Current (Amps) | 0.5 |
PEL Switching Power (Watts) | 10 |
PEL Switching Voltage | 200 |
PEL Diode | No |
PEL Standoff Voltage | 240 |
PEL Switch Type | General Dry Reed |
PEL Height (mm) | 10.2 |
PEL Width (mm) | 19.1 |
PEL Depth (mm) | 4.8 |
