144ES-1-A-12/3D Reed Relay
$25.20 Excl. Vat, Tax and Duties
10 in stock for online purchase
For additional smaller quantities, our current lead time is approximately 14–16 weeks.
Lead time details
For larger volume requirements, lead times may vary. Please contact us (opens in a new tab) to discuss your specific requirements and we will confirm the best achievable lead time.
Key specifications
- Series
- 144
- Coil Voltage
- 12V
- Contact Form
- 1 Form A - SPST N.O.
- Coil Resistance
- 400 Ω
Order options
Buy direct online
For small-quantity orders from available stock.
Request a quote
For larger quantities, scheduled demand or project pricing.
- No obligation
- Response within 1 business day
- Volume pricing
Pickering Series 144
- High Power Dry SIL Reed Relays
- Single-in-Line Reed Relays
- Up to 80 W switching at 1A
- Up to 60 W switching at 2A
- Up to 1kV switching and 3kV standoff
- 12 V Coil
- Electrostatic Screen to reduce noise
- Internal Diode
- Try before you buy with Pickering’s free sample service >
- Designed and manufactured by Pickering in the UK and Czech Republic (EU)
To learn more about this series click here
| Series | 144 |
|---|---|
| Coil Voltage | 12V |
| Contact Form | 1 Form A - SPST N.O. |
| Coil Resistance | 400 Ω |
| Switching Current (Amps) | 2A |
| Switching Power (Watts) | 80W |
| Switching Voltage | 1000V |
| Standoff Voltage | 3000V |
| Diode | Yes |
| Switch Type | General Dry Reed |
| Dimensions | 55663927 × 556629 mm |
|---|---|
| PEL Contact Configuration | 1 Form A – SPST N.O. |
| PEL Switching Current (Amps) | 2 |
| PEL Switching Power (Watts) | 80 |
| PEL Switching Voltage | 1000 |
| PEL Standoff Voltage | 3000 |
| PEL Coil Voltage | 12V |
| PEL Coil Resistance | 400 Ω |
| PEL Diode | Yes |
| PEL Depth (mm) | 6.22 |
| PEL Width (mm) | 24.1 |
| PEL Height (mm) | 8.1 |
| PEL Series | Series 144 |
| PEL Switch Type | General Dry Reed |
