62-1-B-24/2
$86.10 Excl. Vat, Tax and Duties
4-6 weeks for additional manufactured stock
Availability: 5 in stock
Discount per quantity
| Quantity | 1 - 24 | 25 - 99 | 100 - 249 | 250+ |
|---|---|---|---|---|
| Price | $86.10 | $77.49 | $73.19 | $68.88 |
Please note - Prices above excl. tax and duties
For availability, lead time and delivery options please request a quote. For larger quantities fill out this form
Request a Free Sample < Back to the Reed Relay SelectorPickering Series 62
- High Voltage Dry Reed Relays
- For up to 15 kV
- 1 Form B
- 24 V Coil
- Designed and manufactured by Pickering in the UK and Czech Republic (EU)
To learn more about this series click here
Many benefits compared to industry-standard relays. Learn more here
Custom options are available. Learn more here
| Dimensions | 55663927 × 556629 mm |
|---|---|
| PEL Switching Power (Watts) | 50 |
| PEL Diode | No |
| PEL Depth (mm) | 19.05 |
| PEL Width (mm) | 63.5 |
| PEL Height (mm) | 21.3 |
| PEL Series | Series 62 |
| Series | Series 62 |
| PEL Coil Voltage | 24V |
| PEL Switching Current (Amps) | 3 |
| Contact Configuration | 1 Form B – SPST N.C. |
| PEL Switching Voltage | 7500 |
| Switching Power (Watts) | 50 |
| Coil Resistance | 500 Ω |
| PEL Standoff Voltage | 10000 |
| PEL Switch Type | 10KV Standoff |
| Diode | No |
| PEL Contact Configuration | 1 Form B – SPST N.C. |
| Coil Voltage | 24V |
| PEL Coil Resistance | 500 Ω |
| Switching Current (Amps) | 3 |
| Switching Voltage | 7500 |
| Standoff Voltage | 10000 |
| Depth (mm) | 19.05 |
| Width (mm) | 63.5 |
| Height (mm) | 21.3 |
Other Recommended Relays
Quality Assurance
Pickering reed relays are subjected to continuous inspection during the manufacturing process and after a strenuous thermal cycling routine, every reed relay is 100% tested for all operating parameters.
Pickering are certified to ISO 9001:2015 and audited by the British Standards Institution.
