85-1-C-5/7D

$21.65 Excl. Vat, Tax and Duties

13-16 weeks for manufactured stock

No stock available - made to order. Please add to request for quote list

Compare

Please note -  Prices above excl. tax and duties

For availability, lead time and delivery options please request a quote. For larger quantities fill out this form

Request a Free Sample

Check Distributor Inventory

< Back to the Reed Relay Selector

Pickering Series 85

  • General Purpose Reed Relays
  • Dry and mercury wetted
  • 1 Form C
  • 5 V Coil
  • Designed and manufactured by Pickering in the UK and Czech Republic (EU)

To learn more about this series click here

Many benefits compared to industry-standard relays. Learn more here

Custom options are available. Learn more here

Download Data Sheet PDF

Dimensions 55663927 × 556629 mm
PEL Depth (mm)

9.9

PEL Width (mm)

28.9

PEL Height (mm)

9.4

PEL Series

Series 85

PEL Switching Current (Amps)

0.25

Series

Series 85

PEL Switching Voltage

200

Contact Configuration

1 Form C – SPDT Changeover

PEL Standoff Voltage

200

Switching Power (Watts)

3

Coil Resistance

500 Ω

PEL Switch Type

Changeover

PEL Coil Resistance

500 Ω

Diode

Yes

PEL Switching Power (Watts)

3

Coil Voltage

5V

PEL Contact Configuration

1 Form C – SPDT Changeover

Switching Current (Amps)

0.25

PEL Diode

Yes

Switching Voltage

200

PEL Coil Voltage

5V

Standoff Voltage

200

Depth (mm)

9.9

Width (mm)

28.9

Height (mm)

9.4
