3 VOLT RELAYS

by Pickering / Saturday, 17 December 2016 / Published in Product News

Reed Relays with 3 volt operating coils

Pickering Electronics are pleased to announce the release of 3 Volt relays

3 Volt Reed Relays

• 3 volt operating coils now available in most ranges
• Ideal for equipment using 3 volt logic
• 1 Form A versions now available

Versions with 3 volt operating coils are now available in most ranges .These are ideal for equipment using 3 volt logic.

The Series 100 has a coil resistance of 2000 ohms, the Series 101 is 1600 Ohms and the small Series 118 is 1000 Ohms making them ideal for portable equipment.

In some other ranges, we have been able to retain the same coil resistance figures as the 5 volt types. Initially, 1 Form A versions are available but 2 Form A and Form C versions will soon be added so if you have a requirement for these, please contact us, we may have them available.
