Pickering Electronics to Showcase Latest Reed Relays at Southern Manufacturing & Electronics Exhibition

by Pickering / Monday, 17 February 2014 / Published in Media News
Pickering Series 104 High Voltage SIL Reed Relays

Pickering Electronics will be showcasing its latest models at the Southern Manufacturing & Electronics Exhibition on 12 – 13, February 2014 in Stand J66.

Pickering Electronics introduces 3 Volt Reed Relays:

  • 3 volt operating coils now available in most ranges
  • Ideal for equipment using 3 volt logic
  • 1 Form A versions now available Versions with 3 volt operating coils are now available in most ranges.

These are ideal for equipment using 3 volt logic. The Series 100 has a coil resistance of 2000 ohms, the Series 101 is 1600 Ohms and the small Series 118 is 1000 Ohms making them ideal for portable equipment. In some other ranges, we have been able to retain the same coil resistance figures as the 5 volt types.

Initially, 1 Form A versions are available but 2 Form A and Form C versions will soon be added so if you have a requirement for these, please contact us, we may have them available.

Featuring Pickering SoftCenter® Technology Pickering Electronics are manufacturers of high quality Reed Relays for Instrumentation and Automatic Test Equipment (ATE), High voltage switching, Low thermal EMF, Direct drive from CMOS, RF switching and other specialist applications. Pickering Relays are available in Surface Mount, Single-in-Line (SIL), Dual-in-Line (DIL) and many other popular package styles And like our existing relays they incorporate SoftCenter® technology.

You can view the original article here.
