Pickering Electronics, announces the Series 100HV high voltage SIL/SIP reed relays rated for up to 3kV stand-off voltage and with more than double the coil resistance of previous devices. This suits them for applications such as transformer or cable testing or any other automatic test equipment where high voltages are involved but where low coil […]
The Pickering 100 and 101 Series are a complete range of Single-in- Line (SIL) reed relays featuring low thermal EMF and primarily intended for direct drive from CMOS logic IC’s. The 100 series can be driven directly from 4000B CMOS or NMOS logic or similar low current sources, in addition, the mercury wetted relays in the range may be
Pickering reed relays with low thermal EMF for direct drive from Logic ICs Read More »
Pickering Electronics are pleased to announce the new changeover 1 Form C version of our popular Series 67 high voltage PCB relay that saves space and makes design simple.
New HV SPDT Form C Reed Relays Read More »
Pickering Electronics, the reed relay company which has pioneered miniaturization and high performance for over 50 years, has completely revamped the datasheets of its entire range of reed relays, providing more information in a clearer format with interactive links to further useful content.
Pickering delivers clear, comprehensive new information resource. Read More »
Pickering Electronics is pleased to announce the new Series 131. Housed in the miniature SIL/SIP package, new Series 131 reed relays have a footprint of just 12.5mm x 3.7mm and a height of 6.6mm and deliver a minimum stand-off of 1500V.
ULTRA-HIGH DENSITY 4MM REED RELAY Stacking on a 4mm x 4mm pitch, with a profile height of just 12.5mm Switching at 10 Watts, 0.5 Amp Choice of 3 or 5 Volt coils 1 Form A (SPST N.O.) Energize to make Fast operate times – typically 150µs or less Suitable for high speed test, A.T.E. switching
ULTRA-HIGH-DENSITY 4MM RELAY Industry’s Smallest Through-Hole Reed Relay Launched Stacking on a 4mm x 4mm pitch, with a profile height of just 9.5mm 5 Watts, 0.5 Amp switching Choice of 3 or 5 Volt coils 1 Form A (SPST N.O.) Energize to make Ideal for high speed A.T.E. and Semiconductor test systems Pickering Electronics are
HIGH DENSITY 4MM RELAY Reed Relay with the world’s smallest footprint to be released at Semicon West 2017 Highest packing density currently available Switching up to 20 Watts 1 Amp Choice of 3, 5 or 12 Volt coils Stacking on 4mm x 4mm pitch Pickering Electronics are pleased to announce that the new Series 120
HIGH VOLTAGE RELAYS New Series 67 and 68 High Voltage Reed Relays for up to 10kV • PCB Mounting with option of flying lead switch connections • Robust tungsten plated vacuum switches • Plastic package with internal mu-metal magnetic screen • Ideal for cable and transformer test or other high voltage applications
NEW SERIES 67 and 68 Read More »
New Series 119 Micro-SIL Relays for up to 3kV • Sputtered Ruthenium vacuum switches • 1 Form A at 1, 2, or 3kV plus 2 Form A at 1kV • Plastic package with internal mu-metal magnetic screen • Ideal for Mixed Signal ATE, Cable Test or other high voltage applications where space is at a
NEW 119 HIGH VOLTAGE RELAYS Read More »
